098-00720-000 Revision D1 – February, 2018 SyncServer 600 Series User’s Guide 221
Chapter 6 Provisioning
Provisioning Outputs
Provisioning the PTP Server Output
Table 6-17. Configure New PTP Server Output
Method Steps Notes
Web Interface Network Timing > NTPr/PTP Config
1. Use the Service dropdown box to
select PTP master in the “Add
New” row at the bottom of the
window.
2. Use the Profile dropdown box to
select the desired profile in the
“Add New” row.
3. Click the blue Configure icon in the
“Add New” row. The Configurable
Parameters widow will open.
4. Change the parameter settings to
the desired values. Click OK.
5. Click the green +Add button
Network Timing > NTP/PTP Mapping
1. Use the NTPr/PTP Service Name
dropdown box to select the PTP
service name for the desired port.
2. Click the Apply button.
Map PTP master to the
desired LAN port.
CLI n/a n/a
Front Panel n/a n/a
