190 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Chapter 6 Provisioning
Provisioning Input References
Table 6-9. Configure PTP Client Inputs
Method Steps Notes
Web Interface Network Timing > NTPr/PTP Config
1. In the “ADD NEW” row, enter the
User-Defined Name for the
service.
2. In the “ADD NEW” row, use the
Service dropdown box to select
“PTP Client”.
3. In the “ADD NEW” row, use the
Profile dropdown box to select
desired profile.
4. To configure the PTP client, click
the blue Configure icon in the
“ADD NEW” row, The
Configurable Parameters window
will open.
5. Make desired changes to the
configurable parameters. Click the
OK button when done.
6. Click the green ADD button.
Network Timing > NTP /PTP Mapping
1. For the desired LAN port, use the
Service Name dropdown box to
select the desired PTP client
service.
2. Click the Apply button for the port
being mapped.
CLI n/a n/a
Front Panel n/a n/a
