Microsemi SyncServer S650 - F73 - Alarm Status; F73 Alarm Indicators

098-00720-000 Revision D1 – February, 2018 SyncServer 600 Series User’s Guide 157
Chapter 5
SyncServer S6x0 CLI Command Set
F73 - Alarm Status
Use function F73 to view alarm status. The SyncServer S6x0 will return a response
in the follow format:
F73<SP>S<STATUS><SOURCE><SP><123456789ABCDEFGHIJ><CR><LF>
The alphanumeric characters 1-9 and A-J represent specific positions in the
response string shown above. Table 5-3 describes F73’s alarm indicators based on
their position in the response string.
Table 5-3. F73 Alarm Indicators
Syntax Alarm Indicators Description
F n/a n/a ASCII character F
7 n/a n/a ASCII character 7
3 n/a n/a ASCII character 3
<SP> n/a n/a ASCII space character,
one or more
S n/a n/a ASCII character S,
Status delimiter
<STATUS> Clock Status “L” = Locked
“U” = Unlocked
The Clock Status indicator reports
“Locked” when the SyncServer S6x0
clock is locked to a reference source
(e.g., GPS, IRIG, etc.). This is the
normal operational state of the clock.
While locked, the clock steers its internal
oscillator to the reference source.
The Clock Status indicator reports
“Unlocked” when the SyncServer S6x0
clock is not locked to a reference
source. This may be because the
reference source is unlocked or
unstable. While unlocked from a
reference source, the SyncServer S6x0
uses its internal oscillator to keep time
until a reference becomes available
again.
