098-00720-000 Revision D1 – February, 2018 SyncServer 600 Series User’s Guide 225
Chapter 6 Provisioning
Provisioning Outputs
.
Table 6-21. Configure IRIG and Other Outputs on Timing I/O Module
Method Steps Notes
Web Interface Option Slot A > Timing I/O Card
1. For desired output J3-J8, use
dropdown box to select the
general signal output type of
“Pulse”, “Timecode” “Sine” or Off.
2. For TimeCode, use the
dropdown box to select the type
of IRIG:
3. For Pulse, use the dropdown box
to select Fixed Rate or
Programmable Period.
4. For Pulse, use the dropdown box
to select the rate or period.
5. For Sine, use the dropdown box
to select the frequency, 1M, 5M
or 10M.
6. Enter phase offset value (for
fixed-rate pulses or timecode
outputs) It has a range of -0.5 to
0.5 s.
7. Click the Apply button.
Timecode Choices:
- A004 (DCLS, YR, CF, SBS)
- A134 (10Khz, YR, CF, SBS)
- B000 (DCLS, CF, SBS)
- B001 (DCLS, CF)
- B002 (DCLS)
- B003 (DCLS, SBS)
- B004 (DCLS, YR, CF, SBS)
- B005 (DCLS, YR, CF)
- B006 (DCLS, YR)
- B007 (DCLS, YR, SBS)
- B120 (1kHZ, CF, SBS)
- B121 (1kHZ, CF)
- B122 (1kHZ)
- B123 (1kHZ, SBS)
- B124 (1kHZ, YR, CF, SBS)
- B125 (1kHZ, YR, CF)
- B126 (1kHZ, YR)
- B127 (1kHZ, YR, SBS)
- B1344 (DCLS)
- B1344 (1kHZ)
- E115 (100Hz, YR, CF)
- E125 (1KHz, YR, CF)
- G005 (DCLS, YR, CF)
- G145 (100kHz, YR, CF)
- C37.118.1
- NASA 36 (DCLS)
- NASA 36 (1kHz)
- XR3 (250Hz)
- 2137 (1kHz)
- 2137 (DCLS)
CLI n/a n/a
Front Panel n/a n/a
