098-00720-000 Revision D1 – February, 2018 SyncServer 600 Series User’s Guide 301
Appendix C Installing GNSS Antennas
Antenna Kits Overview
Accuracy of the antenna position determined using receiver survey depends on
providing RF gain to the GNSS receiver within a required range of 15 to 30 dB and
locating the antenna with an unobstructed field of view in a low multipath
environment. If these conditions are not met, the receiver survey will either require
longer than 20 minutes to complete or will not complete, preventing the GNSS input
from being used by the system as a reference. Also, timing stability will not be
optimized if these conditions are not met.
Table C-1. GNSS Antenna Kits & Accessories
Antenna Kit Part Number Total Delay (ns)
Kit:
Total length: 50 ft,
Cable: 50 ft; antenna kit (093-15202-001)
990-15202-050 107
Kit:
Total length: 75 ft,
Cable: 50 ft; lightning arrestor (112-43400-00-3);
Cable: 25 ft; antenna kit (093-15202-001)
990-15202-075 137
Kit:
Total length: 100 ft,
Cable: 100 ft; antenna kit (093-15202-001)
990-15202-100 167
Kit:
Total length: 125 ft,
Cable: 100 ft; lightning arrestor (112-43400-00-3);
Cable: 25 ft; antenna kit (093-15202-001)
990-15202-125 198
Kit:
Total length: 150 ft,
Cable: 150 ft; antenna kit (093-15202-001)
990-15202-150 228
Kit:
Total length: 175 ft,
Cable: 150 ft; lightning arrestor (112-43400-00-3);
Cable: 25 ft; antenna kit (093-15202-001)
990-15202-175 258
Kit:
Total length: 200 ft,
Cable: 200 ft; antenna kit (093-15202-001)
990-15202-200 288
Kit:
Total length: 225 ft,
Cable: 200 ft; lightning arrestor (112-43400-00-3);
Cable: 25 ft; antenna kit (093-15202-001)
990-15202-225 319
250 ft. Antenna Cable 060-15202-250 303
350 ft. Antenna Cable 060-15202-350 424
