098-00720-000 Revision D1 – February, 2018 SyncServer 600 Series User’s Guide 223
Chapter 6 Provisioning
Provisioning Outputs
Provisioning the Serial Timing Output
The serial timing outputs (on port labeled "DATA/TIMING") can be configured for
NMEA, NENA, or serial legacy output format.
Table 6-19. Configure Serial Timing Output
Method Steps Notes
Web Interface Timing > Serial
1. Select the NMEA radio button.
2. Click the check box or
combination of check boxes for
the desired type(s) of NMEA
output format:
- NMEA - 0183 ZDA Output
- NMEA - 0183 GGA output
- NMEA - 0183 GSV output
- NMEA - 0183 RMC output
3. Click the Apply button.
Select NMEA output
format.
See
Table 6-21 below for
details about NMEA output
formats.
Timing > Serial
1. Select the NENA radio button.
2. Click the check box for the desired
type of NENA output format.
- DDD HH:MM:SS DTZ=XX
- WWW DDMMMYY HH:MM:SS
- YYYY DDD HH:MM:SS DZZ
3. Click the Apply button.
Select NENA output
format.
NENA ASCII time code is
sent in broadcast mode,
in which the code is sent
once per second at the
beginning of the second
(Data/timing serial port).
Timing > Serial
1. Select the Legacy Serial Output
radio button.
2. Click the Apply button.
F8 - Continuous Time
Once-per-Second
DDD:HH:MM:SSQ
Note:
F9 - Time On Request
DDD:HH:MM:SS.mmmQ
(direct request to Console
port)
Timing > Serial
1. Click the Off radio button at the
top of the dialog box.
2. Click the Apply button.
Turn Serial Timing Output
off.
CLI n/a n/a
Front Panel n/a n/a
