282 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Appendix B Specifications and Factory Defaults
GNSS Antenna Kits Specifications
GNSS Antenna Kits Specifications
The basic antenna kit (093-15202-001) consists of the following
GNSS Antenna (112-00079-000) with internal LNA
Mounting Bracket (193-00044-000)
Adapter cable for chassis (060-15202-004). This cable has an N-connector on
one end and a BNC-connector on the other end.
Other components available in kits or separately include the following:
Lightning arrestor (112-43400-00-3)
Inline Amplifier (112-15202-001)
GPS L1 4:1 Active Splitter (58536A)
See Table 7-7 for antenna kit part numbers.
GNSS Antennas with Internal LNA Specifications
Table B-23 provides specifications for the GNSS antenna with internal LNA.
Note: Holdover values are approximate and assume operation at
constant temperature, no initial frequency or phase offset, and that
the unit has been powered on for 2 weeks and locked to GNSS for
three consecutive days.
Table B-23. GNSS Antenna with Internal Low-Noise Amplifier Specifications
Characteristic Specification
Mechanical
Diameter 66.5 mm
Height 21 mm
Weight 150 grams
Environmental
Operating Temperature -40 to +85 C
