280 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Appendix B Specifications and Factory Defaults
Specifications
LPN Module Output Signal Specifications
The LPN outputs are available with the Optional LPN Module.
Pulse Width  50% for programmable pulse
 20s for fixed-rate pulse periods of PPM,
PP2S, and PPS
 50% for other periods of fixed-rate pulse
Connector type BNC male
Connector Label J3 - J8
Impedance 50 
Table B-20. SyncServer S6x0 LPN Module Output Signal Specifications
Parameter Specification
Phase Noise
1 Hz
10 Hz
100 Hz
1 kHz
10 kHz
100 kHz
– 95 dBc/Hz
–125 dBc/Hz
–145 dBc/Hz
–150 dBc/Hz
–155 dBc/Hz
–155 dBc/Hz
Allan Deviation
1 s
10 s
100 s
<3.0 × 10
–12
<4.5 × 10
–12
<7.0 × 10
–12
Output Level 13 dBm ± 1.5 dB
Channel-to-Channel Isolation 100 dB at 10 MHz
Connector type BNC male
Connector Label J1 - J8
Impedance 50 
Table B-19. SyncServer S6x0 1PPS Output Signal Specifications (Continued)
Parameter Specification
