Microsemi SyncServer S650 - Add a New NTP Association

098-00720-000 Revision D1 – February, 2018 SyncServer 600 Series User’s Guide 205
Chapter 6 Provisioning
Provisioning NTP Associations
.
Table 6-12. Add a New NTP Association
Method Steps
Web Interface NTP > NTPd Config
1. Select the Role with dropdown box as either Server, Peer, or
Broadcast.
2. Enter the IP address or DNS name of the NTP association.
3. Select the Port with dropdown box, LAN1, LAN2, LAN3, LAN4,
LAN5 or LAN6.
4. Click the “Prefer” checkbox to set this as a prefer association.
5. Select the Burst setting with the dropdown box as N/A, Burst,
iBurst, or Both.
6. Select the MinPoll value with the dropdown box.
7. Select the MaxPoll value with the dropdown box.
8. Select the Symmetric key with the dropdown box
9. Click the + button in the right side column to add the
association.
10. Click the Save button to save changes.
11. Click the Restart button to make any changes take effect.
CLI n/a
Front Panel n/a
