Chapter 1 Overview
Physical Description
See Figure 1-27 to view the signal types for the standard configuration and the
configuration with the FlexPort™ option.
Figure 1-26. Timing I/O Module BNC Connectors
Figure 1-27. Signal Types for Timing I/O Module
Low Phase Noise (LPN) Module Connections
The module has eight 10MHz LPN outputs (J1-J8). There are two different LPN
modules available with different performance specifications.
There is no user configuration necessary with these modules.
