098-00720-000 Revision D1 – February, 2018 SyncServer 600 Series User’s Guide 289
Appendix B Specifications and Factory Defaults
GNSS Antenna Kits Specifications
GPS Antenna Coaxial Cable Specifications
Other cable types are available. Table B-29 provides antenna cable specifications.
Before using additional cables, verify that the total antenna system gain is
acceptable.
Table B-29. Antenna Cable Specifications
Cable Type
Loss
(@1.575 GHz dB
per foot)
DC Resistance
( per foot)
Type Center
Conductor
Flammability
RG213/U
(Belden 8267)
0.093 dB 0.0030 Stranded 13 AWG U/L CSA
RG213/U
(Belden 8267)
0.093 dB 0.0030
Stranded 2.62 mm
2
U/L CSA
UHF/VHF
(Belden 9913)
0.058 dB 0.0027 Solid 10 AWG
UHF/VHF
(Belden 9913)
0.058 dB 0.0027
5.26 mm
2
UHF/VHF
(Belden 89913)
0.089 dB 0.0027 Solid 10 AWG Plenum U/L
CSA
UHF/VHF
(Belden 89913)
0.089 dB 0.0027
5.26 mm
2
Plenum U/L
CSA
LMR-400 0.051 dB Shield – 0.00165
Center – 0.00139
0.109 inch Solid
LMR-400 0.051 dB Shield – 0.00165
Center – 0.00139
0.27686 cm
2
Solid
LMR/CNT 240 0.101 dB Inner Conductor –
0.0032
Outer Conductor –
0.00389
.056 inch diameter
Solid BC
LMR/CNT 600 0.034 dB Inner Conductor –
0.00053
Outer Conductor –
0.0012
.176 inch diameter
Solid BCCAI
