276 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Appendix B Specifications and Factory Defaults
Specifications
Output Signals
NTP Output
The timestamps have been compensated for 1000BT. For 100BT, the NTP packets
will have a bias of up to 1 microsecond.
PTP Master Output
PTP outputs are available with the PTP License option.
G00x ± 100 ns
NASA 36 ± 100 ns
XR3 ± 100 ns
2137 ± 100 ns
PTP client ± 1 s, typical
NTP client ± 100 s, typical Server on same subnet
Table B-13. SyncServer S6x0 NTPOutput Signal Specifications
Parameter Specification
Connector Type RJ45
Connector Label Ports
1, 2, 3, 4
Table B-14. SyncServer S6x0 PTP Output Signal Specifications
Parameter Specification
Connector Type RJ45, 100/1000 Base-T
Connector Label Ports 1, 2, 3, 4
PTP Profile Enterprise
Table B-12. Timing Accuracy to Reference (Continued)
Reference
Timing Accuracy to
Reference
Comments
