272 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Appendix B Specifications and Factory Defaults
Specifications
VCCI-A: (This is a Class A product based on the standard of Voluntary Control
council for Interference by Information Technology Equipment (VCCI). If this
equipment is used in a domestic environment, radio interference may occur, in
which case the user may be required to take corrective actions.)
Serial Port
Input Signals
GNSS
Table B-5. SyncServer S6x0 Console Serial Port Specifications
Item Description
Connector Type 9-pin, female D connector
Connector Label CONSOLE
Interface RS-232, data terminal equipment (DTE)
Baud Rate 57.6 Kbps
Data Bits 8
Parity Bit None
Stop Bits 1
Flow Control None
Table B-6. SyncServer S6x0 GNSS Input Signal Specifications
Parameter Specification
Signal Type GNSS L1
Gain Between 15 dB and 30 dB including gain of antenna
and loss of cable
