30 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Chapter 1 Overview
Physical Description
1PPS TI Measurement License:: This license enable 1PPS measurements to be
made on the J1 port of a timing card.
See SyncServer S6x0 Part Numbers, on page 241 for all available options.
Activation keys are associated with the serial number of the device on which the
keys are stored and travel with that device. The user must enter key(s) with web
interface via LAN1 port to gain access to the licensed software options web page.
Security Features
Security is an inherent part of the SyncServer S600/S650 architecture. In addition to
standard security features related to the hardening of the web interface, NTP and
server access, unsecure access protocols are deliberately omitted from the S6x0
while remaining services can be disabled. Advanced authentication services such
as TACACS+, RADIUS, and LDAP are optionally available.
The four (4) standard GbE ports, and optional two (2) 10GbE ports, combined easily
handle more than 10,000 NTP requests per second using hardware time stamping
and compensation (360,000 is max capacity for NTP reflector, 13,000 is max
capacity for NTPd). All traffic to the S6x0 CPU is bandwidth limited for protection
against DoS (denial of service) attacks.
Physical Description
The SyncServer S6x0 consists of a 19-inch (48 cm) rack-mountable chassis, plug-in
modules (S650 only), and hardware.
All connections for the SyncServer S6x0 are on the rear panel. Figure 1-1 is a front
view of the SyncServer S600 version showing LEDs, display screen, navigation
buttons and entry buttons. Figure 1-2 and Figure 1-3 show the rear panel
connections for the Single AC versions of the SyncServer S600. Figure 1-4 and
Figure 1-5 show the rear panel connections for the Dual AC versions of the
SyncServer S600. Figure 1-6 and Figure 1-7 shows the rear panel connections for
the Dual DC versions of the SyncServer S600.
Figure 1-8 is a front view of the SyncServer S650 version showing LEDs, display
screen, navigation buttons and entry buttons. Figure 1-9 and Figure 1-10 show the
rear panel connections for the Single AC versions of the SyncServer S600. Figure
1-11 and Figure 1-12 show the rear panel connections for the Dual AC versions of
the SyncServer S600. Figure 1-13 and Figure 1-14 show the rear panel connections
for the Dual AC versions of the SyncServer S600.
Figure 1-15 is a front view of the SyncServer S650 version showing LEDs, display
screen, navigation buttons and entry buttons. Figure 1-16 shows the rear panel
connections for the Single AC version of the SyncServer S600. Figure 1-17 shows
the rear panel connections for the Dual AC version of the SyncServer S600.
