Microsemi SyncServer S650 - Network Configuration Windows

88 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Chapter 4
Navigation Windows
Network Configuration Windows
The Network tab on the dashboard provides access to windows for Ethernet, SNMP,
SNMP Trap configuration, and Ping.
Network - Ethernet Configuration
Use this window to configure or modify the Ethernet setting for LAN1 - LAN6, and to
manually set the DNS server address for LAN1. There is a separate "Apply" button
for each Ethernet port and the DNS server address configuration.
The following Ethernet parameters can be configured:
 Speed
– Auto | Full 100 | Full 1000
 IP format
– IPv4 | IPv6
 Config
–Static | Dynamic
– IPv6 Auto Config
 IP address
 Subnet mask for IPv4, prefix length for IPv6
 Gateway address
DNS server addresses can be added for LAN1. This will usually be necessary if
LAN1 is configured with a static IP address.
See Figure 4-15. See Appendix E, IP Port Details for information on Ethernet port
isolation, management port rules, and timing port rules.
Note: Each Ethernet port should be configured on a different subnet.
