Chapter 7 Maintenance, Troubleshooting & Part Numbers
SyncServer S6x0 Part Numbers
GNSS Antenna Kits
Antenna cables and accessories enable versatile solutions that are easy to achieve.
Inline GNSS amplifiers installed at the antenna are an easy way to extend cable
runs from 225 feet to up to 900 feet, depending on cable type. Lightning arrestors
provide valuable electrical protection to the SyncServer. Antenna cable splitters
leverage a single antenna and cable for up to four GNSS receivers.
Ordering antenna components is a simple task. The most important thing the user
needs to have is a rough idea of the total cable length needed between the
SyncServer and the mounting location of the antenna. Any extra cable can be coiled
to the side.
Preconfigured kits that include cable, antenna, and related mounting accessories
are available, as shown in Table 7-7. These kits vary by total cable length, and
based on whether a lightning arrestor is required or not. For long cable runs (>225
ft.), the components are assembled individually. See Figure 7-1.
To assist and simplify configuration, Microsemi has an Excel-based antenna
configurator that helps the user determine the exact part numbers they need for the
desired cable length and accessories. See Microsemi’s website for the configurator:
http://www.microsemi.com/products/timing-synchronization-systems/time-frequency
-distribution/network-appliances-servers/syncserver/syncserver-s650#documents.
S650 Modules / Hardware
SyncServer Timing I/O Module 090-15201-006
SyncServer LPN Module 090-15201-007
SyncServer ULPN Module 090-15201-008
10 GbE Card 090-15201-009
S650 Software Enabled Options
Security Protocols License Option 920-15201-102
Flex Timing Option for Timing I/O Module 920-15201-109
PTP Master Option 920-15201-103
PTP Input Option 920-15201-104
Measurement Option 920-15201-111
GLONASS/BEIDOU Option 920-15201-101
Table 7-6. SyncServer S650 Build to Order Part Numbers (Continued)
Item Part Number
