158 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Chapter 5
SyncServer S6x0 CLI Command Set
<SOURCE> Clock Source “A” = Clock to Timing
I/O Slot A
(J1A)
“B” = Clock to Timing
I/O Slot B
(J1B)
“P” = Clock to GNSS
“R” = Clock to External
Input Reference
(J2A/B)
“T” = Clock to NTP
“F”= None
Same as WebGUI “Current Reference”
row in Dashboard > Timing.
This is also equivalent to the “Time input
selected” notification.
“A” and “B” encoding can also occur if
the BNC is configured for 1PPS.
<SP> ASCII space character,
one or more
1 PLL
Synthesizer
“–” = Locked
“C” = Unlocked
The PLL Synthesizer indicator reports
“Locked” during normal operation while
the system clock’s PLL is locked to the
internal oscillator.
The PLL indicator reports “Unlocked” if
the SyncServer S6x0 clock’s hardware
PLL has failed. While the PLL indicator
is “Unlocked”, all SyncServer S6x0 clock
timing parameters are unreliable and
should not be used. Contact Microsemi
FTD Services and Support.
2 “–” = Locked Always “–” for initial release.
3 Primary “–” = OK
“P” = Fault
Indicates OK when GNSS input qualified
for time, which is equivalent to Green
indication for GNSS on Dashboard >
Timing> Timing Reference row. Note
that disabling of GNSS will also
generate “P”.
4 (For future use) “–” = OK Always “–” for initial release.
Table 5-3. F73 Alarm Indicators
Syntax Alarm Indicators Description
