SEQUENCE VALVE GATE
External Wiring Connections
Inputs - European Version
A HAN16 connector provides interconnection for the control inputs as
detailed below:
Circuit Pins Description Format
Alarm Output 5 & 13 Goes to “closed” when an alarm
condition is generated.
Normally
open pair
Analogue
Input 1
6+ & 14 - Accepts a current source input that
relates to a main screw position.
A calibration routine within the
controller adjusts actual input to
actual screw position.
4 to 20
mA
Analogue
Input 2
7+ &15- Accepts a voltage source input that
relates to the main screw position.
A calibration routine within the
controller adjusts actual input to
actual screw position.
0 to 10
volts
Analogue
Input 3
8+ & 16- Accepts a voltage source input
that relates to the secondary screw
position.
A calibration routine within the
controller adjusts actual input to
actual screw position.
0 to 10
volts
Start Trigger 1 & 9 Sees a closed condition as a signal
to start the timer on the valve
sequence
Normally
open pair
Trigger A 2 & 10 Not normally used – reserved for
future use
Digital
Input A
Trigger B 3 & 11 Not normally used – reserved for
future use
Digital
Input B
Enable 4 & 12 Sees a closed condition as a
signal that the injection machine is
ready to start working. Any other
signals present are ignored until the
[
Enable] is present
Normally
open pair
