B
Status • Reports
APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
239
573408-001-a
DEPI Session Stats Window
Use this window to displays information on the status of the DEPI sessions currently
active in the system.
For access, select View Session Status in the DEPI Status window, to display status
specific for a given control connection; alternatively, select View All Sessions to display
status for all active sessions in the system:
Figure 12-14 — DEPI Session Stats window
DEPI Session Stats window field definitions
Item Definition/Range
Ses ID
Identifies the DEPI session.
Ctl ID
Identifies the Control Connection.
QAM
Identifies the output transport stream linked to the specific DEPI
session.
Local UDP
Identifies the incoming UDP port linked to the specific DEPI session.
This value is only meaningful if the session is configured to run over
UDP.
Status
Operational state for the connection, such as Established or Unknown.
Data Pkts Rcv
Number of data packets received belonging to the specific DEPI session.
Data Pkts Discarded
Number of data packets discarded in the specific DEPI session.
Data Pkts Discard Seq Num
Number of Data packets discarded due to a sequence number
discontinuity in the specific DEPI session.
