Installation • Installing or Removing GigE SFP Transceivers
APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
33
573408-001-a
Installing or Removing GigE SFP Transceivers
The GigE requires certified Small Form Factor Pluggable (SFP) transceivers.
• For a list of approved SFP transceivers, reference Certified SFP Transceiver Vendors.
• Refer to vendor documentation for proper handling, cleaning, and maintenance of
SFP transceivers. For further information, visit that vendor’s website:
•
http://www.avagotech.com/
•
http://www.ocp-inc.com
•
http://www.methode.com
•
http://www.finisar.com
• Generic SFP transceiver installation and removal instructions are listed below. Refer
to vendor documentation for specific SFP transceiver installation and removal
instructions.
Installing Transceivers
1. Remove the dust plug from the selected APEX1000 front panel GigE port. Save the
dust plug, should it become necessary to recap the port when not in use.
2. As shown in
Figure 3-2, make certain that the SFP transceiver door is closed and the
hinge faces down, toward the bottom of the APEX1000.
3. Gently push the SFP transceiver into the GigE port.
4. Repeat steps 1–3 to install the remaining GigE SFP transceivers.
Removing Transceivers
1. Open the hinge door of the SFP transceiver.
2. Gently pull the SFP transceiver from the GigE port.
Note: Install a dust plug in the GigE port if it is not being used at this time.
SFP Transceiver Status
To confirm the functionality of certified installed SFPs, use the SFP Status window.
From this window, you can also access the following information:
• Supplier and Motorola part numbers
• Nominal bit rate
• Laser wavelength
• Supply voltage
• Diagnostics
For further details and a complete list of values, reference
SFP Status.
