B
SDV — Switched Digital Video Controls • RTSP Controller Configuration
APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
167
573408-001-a
RTSP QAM Configuration window field definitions
Item Definition
TS:QAM
This field shows the Output Transport Stream # and QAM #.
Group Name
Information that is reported to the ERM and useful for the operator to group
QAMs together.
QAM Channel Name
This is automatically filled from the Streaming Zone and PAT TS ID.
The QAM Channel Name must be in the following format:
Streaming Zone.TSID
Bandwidth Delta (kbps)
The APEX1000 issues an update to the controller when its available bandwidth
changes by a value exceeding this amount.
The default value is 1000.
RTSP Status
This window shows the status of all RTSP connections on the APEX1000, as well as a
map of the (up to) 768 input multicast streams coming in on GigE and going out to QAM
RF:
Figure 8-8 — RTSP Status
Note: 32 rows display at one time. Use the Display Range setting to select the rows to
display.
