Appendix A • Specifications
APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
282
573408-001-a
Parameter Description
Typical
230 W
Maximum
280 W
Operating Environment
Parameter Description
Ambient temperature
32 ºF to 104 ºF (0 ºC to +40 ºC)
Operating humidity
5% to 95% Relative Humidity (non condensing)
Storage temperature
–40 ºF to 158 ºF (–40 ºC to +70 ºC)
Cooling
Five fans
Altitude
–200 feet to 10, 000 feet
ASI Monitor Port
Parameter Description
MPEG input
ASI front panel BNC connector
ASI impedance
75 Ohms
ASI Data Rate
Line rate
270 Mbps
Output data rate
Variable: 1 Mbps to 206 Mbps
Output format
188 mode only
Voltage range
800 mVpp ±10%
• The maximum MPEG throughput across a single GigE interface pair is 931 Mbps,
assuming 24 QAMs active with a 38.81 Mbps data rate.
• The maximum MPEG throughput across the APEX1000 is 1.863 Gbps, assuming 48
QAMs active with a 38.81 Mbps data rate.
• Including headers, the maximum data rate at GigE inputs is 1.976 Gbps (3.952 Gbps
assuming input redundancy).
