PSIP Status
The following table shows the PSIP status per service. For each service, the service
number, the Output Transport Stream number, its PSIP state and its source id are shown
in the current entry.
Figure 12-32 — PSIP Status
Note: Due to the table’s reception rates defined by users, and the internal process in the
EQAM, these statistics may take up to two minutes (given that PSIP is enabled until all
the parameters displayed are updated).
PSIP Status window field definitions
Item Definition
Index
Output Program Table Index.
Service #
Current Output Service Number.
Output TS
Current Output Transport Stream of this service.
Source ID
Current PSIP Program Source Id.
Service State
Current program PSIP state.
