Installation • Package Contents
APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
29
573408-001-a
3
Installation
Step-by-Step Instructions
The following topics cover the basic steps required to install the APEX1000:
• Mounting the APEX1000
• Connecting the Interface Cables
• Applying Power to the Unit
• Confirming APEX1000 Power-on Sequencing
To make the procedure as quick and easy as possible, take a few minutes to review the
installation information, gather any special tools, procure any
items not supplied with
shipment, and complete the tasks listed below before you begin the installation.
Package Contents
Confirm that you have received the following items with the APEX1000 shipment:
Item Quantity Description
APEX1000 unit
1 The APEX1000 device configured with
hardware as ordered
Mounting screws, 10-32, 0.5 inches
long, Phillips, round, with plastic
washer
4 Provided to mount front of unit in the
rack
Rear mounting brackets
2 Provided to support rear of unit in the
rack
Mounting screws, 10-32, 0.5 inches
long, Phillips
4 Provided to mount rear brackets to the
rack
As applicable:
AC cord, 3 conductor, 7 feet 6
inches, 18AWG
or
DC cord, 3 conductor, 15 feet
1 or 2
(depending on
ordering criteria)
Power cord(s) for unit
