Appendix E • RFPM and Power Supply Modules
APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
302
573408-001-a
E
Appendix E
RFPM and Power Supply Modules
The APEX1000’s three RF Plug-in Modules (RFPM) are hot-swappable, and are plugged
into the chassis from the rear of the chassis.
The modules slide onto rails and mate with a high-speed docking connector on the main
board, as shown below:
