Configuration • Chassis Redundancy Configuration
APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
82
573408-001-a
Redundancy Configuration
The following table describes the values found in the Redundancy Configuration portion
of the
Chassis Redundancy Configuration window:
Parameter Description
Chassis Redundancy Enable
Check this box to enable/disable the chassis configuration.
Redundancy Role
Use this menu to configure the desired APEX 1000 role.
Values are:
• Primary – Configures this APEX as the primary APEX (active
output ports)
• Secondary – Configures this APEX as the secondary APEX
(inactive with output ports muted until a failover occurs)
The default is Primary.
Redundancy Mode
Defines the Multicast Redundancy Mode.
Values are:
• Hot – Indicates that mappings are enabled and multicast routes
are joined by the APEX even when it is in standby
• Warm – Shows that multicast routes are joined and routes
enabled only when the APEX is active
The default is Hot.
Redundant APEX IP
Shows the IP of the dedicated redundant APEX heartbeat
interface.
UDP Port
Shows the UDP Port of the designated primary or secondary
APEX.
Suspend Switch Over
Check this box to suspend this APEX from switching over.
When in a suspended state, this APEX does not transition to an
active state even if the other APEX fails. This option allows you to
reboot and/or reconfigure the active APEX and prevent the
standby APEX from coming online. (If the active APEX fails, the
standby APEX does not become active until the suspend switch
over parameter is disabled.)
Note: The configuration is not synchronized when the standby
APEX is suspended.
