Appendix A • Certified SFP Transceiver Vendors
APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
287
573408-001-a
DTI Client RJ45 Interconnect Scheme
RJ45 Pin Number Signal
1
GND
2
10.24 MHz +
3
10.24 MHz -
4
GND
5
NC10 kHz frame clock
6
Serialized Data (client only)
7
GND
Certified SFP Transceiver Vendors
The GigE requires Small Form Factor Pluggable (SFP) transceivers. The APEX1000 is
product– and certification–approved, based on the following Multi-Source Agreement
(MSA) compliant SFP transceiver vendors:
Type Description Supplier Supplier Part Number
Motorola Part
Number
Connector
Avago
Technologies
AFBR-5710LZ N/A
Finisar FTLF8519P2BNL N/A
Optical
850nm SX,
RoHS
Finisar N/A 551742-002-00
LC
Avago
Technologies
AFCT-5710LZ N/A
Finisar FTLF1319P1BTL N/A
Optical
1310nm LX,
RoHS
Finisar N/A 551755-001-00
LC
OCP TRXAG1YXHBYM5 N/A
Finisar FTLF1519P1xCL N/A
Optical
1550nm ZX,
RoHS
Finisar N/A 551767-001-00
LC
Methode
Electronics
DM7041-R-L N/A
Copper
1000bT,
RoHS
Methode
Electronics
N/A 551771-002-00
RJ-45
Note: Items with a Motorola part number are orderable directly from Motorola. Items
that do not have a Motorola part number are supported, but must be ordered direct from
the SFP manufacturer (supplier part number provided).
