Moxy MT 31 - Fitting the Flywheel

SHOP MANUAL MT26-31 - 06.2005
Engine
Tier-3 710655-
Ch 1 page 96
1.
Fit two guide pins 8412 in the crankshaft flange.
2.
Fit the flywheel on the crankshaft.
NOTE!
Always use new bolts and washer .
3.
Lock the flywheel using tool:
- 512563 for engines with unit injector.
4.
Torque tighten the bolts alternately to
130 Nm and then a further 90°.
5.
Fit the engine speed sensors).
Fitting the flywheel
99 411
120 167
512563
