Moxy MT 31 - Renewing Seals

Engine
SHOP MANUAL MT26-31 - 06.2005
Tier-3 710655-
Ch 1 page 119
Renewing seals
1.
Remove the side cover and oil cooler from
the block.
2.
Remove the 4 bolts securing the oil cooler to
the side cover.
3.
Remove the oil cooler.
4.
Renew the 4 O-rings.
5.
Fit the oil cooler insert and bolt securely to
the side cover using 26 Nm torque.
6.
Bolt the side cover to the block.
