TRANSMISSION
Ch 2 page 140 Ch 2 page 141
TRANSMISSION
TRANSMISSION
Ch 2 page 140 Ch 2 page 141
TRANSMISSION
Disassemble the exhaust parts
Disassemble the front V-clamp and the rear clamp,
remove the exhaust pipe.
Disassemble the rear pipe V-clamp and the front and rear suspen-
sions.
Screw M12x30 ISO4017-10.9
Lift out the muffler with the suspension bracket
