Place wheel chocks to the front wheel
Removal of transmission, ass’y
NOTE!
Place the dump truck on level ground and apply parking
brake
Start with the propeller shaft in the articulation hinge.
For best working, start the engine and turn the machine to full
right direction.
Release articulation propeller shaft from the transmission output
flange.
Start the engine and line up the machine
Apply articulation lock.
Turn off main switch in battery case.
Raise the dump body and lock it with the safety support.
Prepare to drain the hydraulic oil:
By pumping a several times (20 - 25) with the brake pedal, to
emptying the 5 brake accumulators.
