TRANSMISSION
Ch 2 page 58
Display during operation
symbol meaning remarks
1F, 1R
2F, 2R
3F, 3R
4F
5F
6F
LF, LR
actual gear and direction
left digit shows actual gear
right digit shows actual direction
limp home gear
F or R, no gear Clutch Cutoff
F od R flashing only 6WG:
direction F or R selected while
turbine speed is too high, CAUTION
gear will engage if turbine speed
drops
NN not neutral, waiting for neutral after
power up or a severe fault
go engage a gear, first move shift selector to
neutral position and again to F or R position
** oil temperature too low, no gear
available
warm up engine / transmission
*N oil temperature low, only one gear
available
warm up engine / transmission
1 bar (special
symbol)
manual mode 1. gear
2 bars manual mode 2. gear
3 bars manual mode 3. gear
4 bars manual mode 4. gear
4 bars and 2
arrows
automatic mode
bars flashing 6 WG: converter lockup clutch open
4 WG: Downshift mode activ
difference of engine and turbine speed above a
certain limit and lockup clutch not activated
spanner at least one fault activ select neutral to get fault code displayed
fault code see faultcode list
WS warning sump temperature changes between actual gear/direction while
driving, in neutral only displayed if no fault is
detected (spanner)
WR warning retarder temperature changes between actual gear/direction while
driving, in neutral only displayed if no fault is
detected (spanner)
WT warning torque converter
temperature
changes between actual gear/direction while
driving, in neutral only displayed if no fault is
detected (spanner)
WE warning high engine speed changes between actual gear/direction while
driving, in neutral only displayed if no fault is
detected (spanner)
PN direction F or R selected while
parking brake engaged
transmission in neutral until parking brake is
released
CAUTION: vehicle starts to move after release of
parking brake
F od R flashing direction F or R selected while
turbine speed is to high, CAUTION
gear will engage if turbine speed
drops
EE flashing no communication with display checked wiring from TCU to display
