The oil change must be carried out as follows:
- At operating temperature of the transmission, horizontally standing vehicle, open the oil
drain plug and drain the used oil.
- Clean the oil drain plug with magnetic insert and the sealing surface on the housing and
install it along with new O-ring again.
- Fill in oil (about 33 liters) according to List of lubricants TE-ML 03. (See chapter 2.0)
The indicated value is a guide value.
It is imperative to pay attention to absolute cleanliness of oil and filter !
Binding is in any case the marking on the oil dipstick !
- Start the engine, idling speed.
- Transmission in Neutral position „N“
- Top up oil up to the marking „COLD - MIN“
- Brake the vehicle securely in position and warm up the transmission
- Shift all Controller positions through
- Check the oil level once more and top up oil once more if necessary
- On the oil dipstick, the oil level must be lying in the Zone „HOT“ (see Figure previous side)
- Insert the oil dipstick again and tighten it by clockwise rotation.
At the initial filling of the transmission has to be considered that the oil cooler, the
pressure filter as well as the pipes must get filled with oil. According to these cavities, the oil
capacity tobe filled in is greater than at the later oil fillings in the course of the usual
Maintenance service.
Moxy recommends, to start the AEB at every oil change.
If the oil quality are changed it is strongly necessery to run AEB !
(see Procedure to start AEB)
Filter replacement:
At the replacement of the Filter in the main oil stream, pay attention that no dirt or oil
sludge can penetrate into the circuit. Besides, the parking brake has to be covered, resp. pro-tected
from oil wetting.
At the mounting of the filter, any exertion of force has to be avoided.
Treat the filter carefully at the installation, the transport and the storage !
Damaged filters must no more be installed !
The filter differential pressure valve (bypass valve) is equipped with a filter contamination
switch which is informing the driver about the contamination of the Fine filter.
At the lighting up of the symbol, the Fine filter must be replaced.
The mounting of the filter must be carried out as follows:
- Cover the gasket with a small amount of oil.
- Screw the filter in until contact with the sealing surface is obtained and tighten it now by
hand about 1/3 to 1/2 turn.
The coarse filter (see Figure previous side) is located in the suction line for the
transmission pump in the manual transmission,
and must be cleaned at every oil change !
Oil change and Oil filling capacity:
