Moxy MT 31 - 0.4 Location of Main Components

SHOP MANUAL MT26/31 - 12.2004SHOP MANUAL MT26/31 - 12.2004
GENERAL
CH 0 PAGE 22 CH 0 PAGE 23
GENERAL
SHOP MANUAL MT26/31 - 12.2004SHOP MANUAL MT26/31 - 12.2004
GENERAL
CH 0 PAGE 22 CH 0 PAGE 23
GENERAL
Tail Gate
Head/Parking
Light/
Turn Signal light
Roof Hat
Hydraulic
Tank
Dumper
Body
Fuel tank
Tilt Cylinder
Bonnet
Lock
Fig 8.1 Location of Main Comoponents
Cab
Bonnet
0.4 Location of Main Components
