The List of lubricants will be updated every two years and can be requested, resp.
inspected as follows:
Moxy Engineering as
6440 Elnesvågen
Norway
At the oil level check, the prescribed safety directions according to § 6 of the
rules for accident prevention for power plants in Germany, and in all other
countries the respective national regulations have to be absolutely respected.
For example, the vehicle has to be secured against rolling with blocks, articula-ted
vehicles additionally against unintended turning-in.
The oil level check must be carried out as follows:
- Oil level check accordance to the MT40B Instruction Manual
- at horizontally standing vehicle
- Transmission in Neutral position „N“
- in the cold start phase, the engine must be running about 2 – 3 minutes at idling speed, and
the marking on the oil dipstick must then be lying above the cold start mark „COLD MIN“
(see Figure-next page)
- at operating temperature of the transmission (about 80° - 90 °C)
- at engine idling speed
- loosen oil dipstick by counterclock rotation, remove and clean it
- insert oil dipstick slowly into the oil level tube until contact is obtained, and pull it out
again.
- On the oil dipstick, the oil level must be lying in the zone „HOT“ (see Figure-next page)
- insert the oil dipstick again, and tighten it by clockwise rotation
If the oil level has dropped in operating temperature condition below the „HOT“
Zone, it is absolutely necessary to replenish oil according to the oil list of lubricants
TE-ML-03.
An oil level above the „HOT“ marking, is leading to a too high oil temperature.
Oil grade
Oil level check:
