Ch 2 page 89
TRANSMISSION
Measuring of resistance at actuator/sensors and
cable
R
2
1
G
Actuator:
Open circuit: R
12
» R
1G
» R
2G
» ¥
Short cut to ground: R
12
» R; R
1G
» 0, R
2G
» R or R
1G
» R, R
2G
» 0
(for s.c. to ground, G is connected to vehicle ground)
Short cut to battery: R
12
» R; R
1G
» 0, R
2G
» R or R
1G
» R, R
2G
» 0
(for s.c. to battery, G is connected to battery voltage)
Cable:
Open circuit: R
12
» R
1P
» R
1C
» R
2P
» R
2C
» ¥
Short cut to ground: R
12
» 0; R
1C
» R
2C
» 0, R
1P
» R
2P
» ¥
Short cut to battery: R
12
» 0, R
1C
» R
2C
» ¥, R
1P
» R
2P
» 0
P (power supply)
1
2
TCU
Actuator /
Sensor
U
Bat
Gnd
C (chassis)
