Engine speed: max. min
-1
.........................................................750 - 2600
Starting torque multiplication: ..............................................................2 to 3,0
Mass (without oil): kg about ........................................................... 900
The Transmissions 6 WG-310 are composed of a hydrodynamic torque converter and a rear-mounted multi-
speed powershift transmission with integrated transfer case
(See: Transmission cross section next page)
The torque converter is a wear-free starting device which is infinitely variable adapting itself to the required situ
-
ations (necessary input torque).
Input via universal shaft with Mechanic flange.
Between engine and torque converter, a Retarder (fluid brake) is arranged whereby a good braking effect will
be achieved in all speeds.
The transmission is shifted manually or fully-automatically by means of the Electronic unit EST-37.
Torque converter:
Unit with torque multiplication according to the version and a WK.
Powershift transmission:
6 Forward speeds and 3 Reverse speeds.
Technical data
Transmission ratio mechanical.
Description:
SPEED DRIVING
DIRECTION
RATIO
1 Forward 5,350
2 Forward 3,445
3 Forward 2,206
4 Forward 1,421
5 Forward 0,969
6 Forward 0,624
1 Reverse 5,350
2 Reverse 2,206
3 Reverse 0,969
