Fasten the complete transmission on the assembly car.
(S) Assembly car 504213
(S) Clamping bracket 504214
Disassembly the retarder
Figure 52
Figure 51
Figure 50
Remove components.
Cover is spring-loaded.
Separate pipes from selector housing.
Loosen hex. head screws and separate pressure regulator from
housing.
Summary for the Tools for retarder disassembly and as
-
sembly, see previous side
