TRANSMISSION
Ch 2 page 252 Ch 2 page 253
TRANSMISSION
TRANSMISSION
Ch 2 page 252 Ch 2 page 253
TRANSMISSION
Figure 447
Press needle sleeve (arrow) with the reinforced shell facing the
pressing-in tool until contact is obtained.
(S) Pressing-in tool 504168
Figure 448
Figure 450
Figure 449
Insert disc s = 1,3 mm and position bearing outer race until
contact is obtained.
Supercool pump to about - 80° C.
Install two adjusting screws and introduce pump until contact is
obtained.
Observe radial installation position!
Use protective gloves!
(S) Adjusting screws 504186
Install O-ring (arrow) and grease it.
Hydraulic pump
