Safety Instructions
Appropriate Use
Use the 223 and 233 pumps only for dispensing lubricants
in centralized lubrication systems. The pump is designed
for intermittent operation.
Misuse
Any use of the 223 and 233 pumps that is not expressly men-
tioned in this User Manual will be regarded as misuse.
If the 223 and 233 pumps are used or operated in a different
manner other than specified, any claim for warranty or liability
will be null and void.
6001a02
NOTE
If personal injury or material damage
occurs as a result of inappropriate opera-
tion, e.g. if the safety instructions are
ignored or resulting from an incorrect
installation of the 223 and 233 pumps, no
claims or legal actions may be taken
against Lincoln GmbH & Co. KG.
Exclusion of Liability
The manufacturer of the pumps 223 and 233 will not accept
any liability for damages:
caused by a lack of lubricant due to an irregular refilling of
the pump;
caused by the use of contaminated lubricants;
caused by the use of greases which are not or only condi-
tionally pumpable in centralized lubrication systems (see
page 45 and 46);
caused by chemical or biological modifications of the
lubricant used;
caused by inadequate disposal of used or contaminated
lubricants as well as of components that have been in
touch with lubricant;
caused by unauthorized modification of the system com-
ponents;
caused by the use of unapproved parts.
Disposal
Dispose of used or contaminated lubricants as well as of
parts that were in touch with lubricant according to the legal
regulations pertaining to environmental protection. Make sure
to observe the safety data sheets of the lubricants used.
Regulations for Prevention of Accidents
To prevent accidents, observe all city, state and federal
safety regulation of the country in which the product will
be used.
Avoid the operation with
unapproved parts.
insufficient or contaminated lubricants.
General Safety Instructions
Lincoln Quicklub centralized lubrication systems
- are designed state-of-the-art.
- can be assembled for safe operation.
Incorrect use may result in bearing damage caused by
poor or over-lubrication.
Unauthorized modifications or changes to an installed
system are not admissible. Any modification must be sub-
ject to prior consultation with the manufacturer of the lu-
brication system.
Installation
Any safety equipment already fitted to the vehicle or the
machine:
- should not be modified or made ineffective;
- should only be removed for the purpose of fitting the
system;
- must be reinstalled after fitting the system.
Keep Quicklub centralized lubrication systems away from
sources of heat. Adhere to the operating temperature.
Use only original Lincoln spare parts (see Parts Catalog)
or parts approved by Lincoln.
Adhere to:
- the installation instructions of the vehicle or machine
manufacturer as regards all drilling and welding proce-
dures.
- the specified minimum distances between the boreholes
and the upper/lower rim of the frame or between two
boreholes.
Operation, Maintenance and Repair
4273a00
CAUTION!
The centralized lubrication system may be
installed by qualified personnel only. Be-
fore beginning with the installation or
service work, disconnect the power
supply!
4273a00
ATTENTION!
Consider residual ripple of max.
±
5 % to
connect pumps with direct current version
(in relation to the operating voltage acc. to
DIN 41755).
Suitably pack defective printed circuit boards and return to
the factory (see page 33, paragraph „Printed Circuit
Boards“).
