31
S.C. TO BATTERY VOLTAGE OR
O
.C. AT ENGINE SPEED INPUT
TCU measures a voltage
higher than 7.00 V at speed
input pin
cable is defective and is
contacted to battery
voltage
cable has no connection
to TCU
speed sensor has an
internal defect
connector pin is contacted
to battery voltage or has
no contact
OP-Mode: substitute
clutch control
check the cable from
TCU to the sensor
check the connectors
check the speed
sensor
32
S.C. TO GROUND AT ENGINE
SPEED INPUT
TCU measures a voltage
less than 0.45V at speed
input pin
cable / connector is
defective and is contacted
to vehicle ground
speed sensor has an
internal defect
OP-Mode: substitute
clutch control
check the cable from
TCU to the sensor
check the connectors
check the speed
sensor
33
LOGICAL ERROR AT ENGINE
SPEED INPUT
TCU measures a engine
speed over a threshold and
the next moment the
measured speed is zero
cable / connector is
defective and has bad
contact
speed sensor has an
internal defect
sensor gap has the wrong
size
OP-Mode: substitute
clutch control
check the cable from
TCU to the sensor
check the connectors
check the speed
sensor
check the sensor gap
This fault is reset after
power up of TCU
Fault
Code
(hex)
MEANING OF THE FAULT
CODE
Possible reason for fault
detection
Reaction of the
TCU
Possible steps
to repair
Remarks
S.C. TO BATTERY
VOLTAGE OR O.C. AT
DLM TRACTION ADJUST
DASHBOARD DEVICE
INPUT
The measured voltage is too
high:
Cable is defective and is
contacted to battery
voltage
Cable has no connection
to TCU
Sensor has an internal
defect
Connector pin is contacted
to battery voltage or is
broken
TCU uses default value
OP-Mode: normal
Check the cable from
TCU to the sensor
Check the connectors
Check the DLM Traction
Adjust dashboard device
2F
