SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
Ch 2 page 77
TRANSMISSION
Fault
Code
(hex)
MEANING OF THE FAULT
CODE
Possible reason for fault
detection
Reaction of the
TCU
Possible steps
to repair
Remarks
S.C. TO GROUND AT
RELAY STARTER
INTERLOCK
TCU detected a wrong
voltage at the output pin,
that looks like a s.c. to
vehicle ground
Cable is defective and is
contacted to vehicle
ground
Starter interlock relay has
an internal defect
Connector pin is contacted
to vehicle ground
No reaction
OP-Mode: normal
Check the cable from
TCU to the starter
interlock relay
Check the connectors
from starter interlock
relay to TCU
Check the resistance
1)
of starter interlock
relay
1)
see chapter 4
1)
see chapter 4
1)
see chapter 4
S.C. TO BATTERY
VOLTAGE AT RELAY
STARTER INTERLOCK
TCU detected a wrong
voltage at the
output pin, that looks like
a s.c. to battery voltage
Cable is defective and is
contacted to battery
voltage
Starter interlock relay has
an internal defect
Connector pin is contacted
to battery voltage
Check the cable from
TCU to the starter
interlock relay
Check the connectors
from starter interlock
relay to TCU
Check the resistance
1)
of starter interlock
relay
No reaction
OP-Mode: normal
O.C. AT RELAY STARTER
INTERLOCK TCU detected
a wrong voltage at the
output pin, that looks like
a o.c. for this output pin
Cable is defective and
has no connection to
TCU
Starter interlock relay
has an internal defect
Connector has no
connection to TCU
No reaction
OP-Mode: normal
Check the cable from
TCU to the starter
interlock relay
Check the connectors
from starter interlock
relay to TCU
Check the resistance
1)
of starter interlock
relay
94
95
96
