SHOP MANUAL MT26-31 - 06.2005
Engine
Tier-3 710655-
Ch 1 page 8
Slack the transmission belt.
Disassemble the ground wiring.
Detach the Air Cond. compressor with the hoses on, from the
engine. Check that all of the clamps are undone.
Place the Air condition compressor on the left while the engine is
dismount.
Disconnect the hose from the termostathousing,
the pipe between the air cooler and the engine air inlet.
Disconnect bracket for the air pipe and bracket between engine
and fan rack
Disconnect the outlet pipe bend from turbo, and the inlet water
hose from the transmission cooler.
Disconnect the retur hose. (Engine - ekspantionstank)
(Quick release coupling)
(Front of the engine, view from the right hand side)
