SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
TRANSMISSION
Ch 2 page 148 Ch 2 page 149
TRANSMISSION
TRANSMISSION
Ch 2 page 148 Ch 2 page 149
TRANSMISSION
Figure 123
Figure 126
Figure 125
Figure 124
Pull oil feed flange by means of special device out of the converter
bell.
(S) Puller device 504160
Remove shim.
Loosen screw connection (M8 and M12). Separate converter bell
from the transmission using lifting device.
(S) Lifting chain 504198
(S) Set of eye bolts 504182
Remove converter safety valve (ball + spring, see arrow).
