TRANSMISSION
Ch 2 page 234 Ch 2 page 235
TRANSMISSION
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
TRANSMISSION
Ch 2 page 234 Ch 2 page 235
TRANSMISSION
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
Figure 392
Figure 395
Figure 394
Figure 393
Heat up bearing inner race until contact is obtained.
Use protective gloves!
Squeeze in and engage both rectangular rings (arrows).
Fix output shaft by means of snap ring (arrow).
Introduce output shaft.
