Engine
SHOP MANUAL MT26-31 - 06.2005
Tier-3 710655-
Ch 1 page 21
Measurement
Boost pressure - filtered value
Boost pressure - filtered value
1
2
6
5
4
3
Boost pressure - filtered value
1. Move text line from the A section to B
2. Start the logging by the start button
3. Select "Viev the list" to watch the values or -
4. Move text linr to section C
5. select the "Osciloscope" to view the graphical diagram
6. Stop logging to select new variable
A
B
C
