Moxy MT 31 - Page 49

Engine
SHOP MANUAL MT26-31 - 06.2005
Tier-3 710655-
Ch 1 page 25
CID Description Limits
Typical
Value
Unit
MT
Value
FCB7
Reaction due to low oil pressure 0, 1, 2, 6
0 = Alarm only
1 = Torque limitation
2 = Stop engine
6 = Stop engine with override option
FCB6
Reaction due to high coolant temperature 0, 1, 2, 3, 0/1/6
0 = Alarm only
1 = Torque limitation on low limit
2 = Stop engine on high limit
3 = Torque limitation and stop engine
6 = Stop engine with override option
7 = Torque limitation and stop engine with
override option
FCAF Engine coolant temperature shut-off limit 0 - 150 105 °C 105
FCF3 Engine coolant temperature torque limitation limit 0 - 150 95 °C 102
FCB5
Reaction on CAN or accelrator pedal error
0, 1, 2, 3,
4, 8
0/1
0 = No action, low level
1 = Increased low idle
2 = CAN shut-off
3 = CAN shut-off and increased low idle
4 = AUX_AN as redundant accelrator pedal
8 = Always use AUX_AN accelrator pedal
FC81 PTO mode 0, max engine speed 0 - 3200 3000 rpm 3000
FC82 PTO mode 1, max engine speed 0 - 3200 3000 rpm 3000
FC83 PTO mode 3, max engine speed 0 - 3200 3000 rpm 3000
FC80 PTO mode 3, fixed engine speed 0 - 3200 1500 rpm 1100
FD09 PTO mode 0, max torque 0 - 5100 5100 rpm 5100
FD0B PTO mode 1, max torque 0 - 5100 5100 rpm 5100
FD0D PTO mode 2, max torque 0 - 5100 5100 rpm 5100
FD0F PTO mode 3, max torque 0 - 5100 5100 rpm 5100
