TRANSMISSION
Ch 2 page 296 Ch 2 page 297
TRANSMISSION
TRANSMISSION
Ch 2 page 296 Ch 2 page 297
TRANSMISSION
Figure
Figure
Figure
Figure
At the following assembly sequence, pay
attention to the installation position of the
components, see also Perspective Illustration/
Page 4.14 !
Oil the components according to ZF-List of
lubricants TE-ML 05 !
Install both thrust washers.
Introduce side gear until both inner plates are accommodated
Introduce thrust ring.
Introduce plate pack A.
Pay attention to the Note, Page 4.14 !
