Engine
SHOP MANUAL MT26-31 - 06.2005
Tier-3 710655-
Ch 1 page 61
IMPORTANT!
Make sure the pushrods are
placed in their correct positions. Make sure the
pushrod to the unit injector is firmly secured in
its lower position by the retaining ring.
IMPORTANT!
If the rocker arms have been
removed on more than one cylinder, the rocker
arm lock bolts must be completely unscrewed
before adjustment commences.
6
Refit the rocker arm shaft. Screw in the
bolts alternately so that they are tightened in
parallel or one of the bolts may bend.
Tighten the bolts to 105 Nm.
7
Check and adjust the unit injector as
described in the section:
Testing & Adjusting / Checking/adjusting the injector rockers.
IMPORTANT!
Make sure that the cable
terminals are the right way round when fitting
the cables to the unit injector.
8
Reconnect the cables on the unit injectors.
Their relative position is not important. Use
torque screwdriver 588 179 to tighten the
screws to 2 Nm.
