Dumper
Body
Tilt Bearing
Rear
Frame
Optional Tail
Gate
Fig 8.1 Rear Wagon Overview
Tilt Cylinders
Ref.Chapter 5.12
Wheels,
Axles and
Drive Shafts
Ref. Chap-
ter 3
Tail gate
Operating
Chain
8.1 Introduction
The Rear Wagon main part is the rear frame which is the base for the dumper body, and the support for the rear
axles.
The rear wagon is connected to the front wagon in the articulation bearing.
The tiltable dumper body is attached to the rear frame in the tilt bearing.
For work on the rear wagon drive line,
ref. chapter 3
